Structured outputs with OpenAI, a complete guide with instructor

OpenAI is the primary integration for Instructor, offering robust support for structured outputs with GPT-3.5, GPT-4, and future models. This guide covers everything you need to know about using OpenAI with Instructor for type-safe, validated responses.

Quick Start

Instructor comes with support for OpenAI out of the box, so you don't need to install anything extra.

pip install "instructor"

⚠️ Important: You must set your OpenAI API key before using the client. You can do this in two ways:

  1. Set the environment variable:
export OPENAI_API_KEY='your-api-key-here'
  1. Or provide it directly to the client:
import os
from openai import OpenAI
client = OpenAI(api_key='your-api-key-here')

Simple User Example (Sync)

import os
from openai import OpenAI
import instructor
from pydantic import BaseModel

# Initialize with API key
client = OpenAI(api_key=os.getenv('OPENAI_API_KEY'))

# Enable instructor patches for OpenAI client
client = instructor.from_openai(client)

class User(BaseModel):
    name: str
    age: int

# Create structured output
user = client.chat.completions.create(
    model="gpt-4o-mini",
    messages=[
        {"role": "user", "content": "Extract: Jason is 25 years old"},
    ],
    response_model=User,
)

print(user)
#> User(name='Jason', age=25)

Simple User Example (Async)

import os
from openai import AsyncOpenAI
import instructor
from pydantic import BaseModel
import asyncio

# Initialize with API key
client = AsyncOpenAI(api_key=os.getenv('OPENAI_API_KEY'))

# Enable instructor patches for async OpenAI client
client = instructor.from_openai(client)

class User(BaseModel):
    name: str
    age: int

async def extract_user():
    user = await client.chat.completions.create(
        model="gpt-4-turbo-preview",
        messages=[
            {"role": "user", "content": "Extract: Jason is 25 years old"},
        ],
        response_model=User,
    )
    return user

# Run async function
user = asyncio.run(extract_user())
print(user)
#> User(name='Jason', age=25)

Nested Example

from pydantic import BaseModel
from typing import List
import os
from openai import OpenAI
import instructor
from pydantic import BaseModel

class Address(BaseModel):
    street: str
    city: str
    country: str

class User(BaseModel):
    name: str
    age: int
    addresses: List[Address]

# Initialize with API key
client = OpenAI(api_key=os.getenv('OPENAI_API_KEY'))

# Enable instructor patches for OpenAI client
client = instructor.from_openai(client)
# Create structured output with nested objects
user = client.chat.completions.create(
    model="gpt-4o-mini",
    messages=[
        {"role": "user", "content": """
            Extract: Jason is 25 years old.
            He lives at 123 Main St, New York, USA
            and has a summer house at 456 Beach Rd, Miami, USA
        """},
    ],
    response_model=User,
)

print(user)
#> {
#>     'name': 'Jason',
#>     'age': 25,
#>     'addresses': [
#>         {
#>             'street': '123 Main St',
#>             'city': 'New York',
#>             'country': 'USA'
#>         },
#>         {
#>             'street': '456 Beach Rd',
#>             'city': 'Miami',
#>             'country': 'USA'
#>         }
#>     ]
#> }

Multimodal

We've provided a few different sample files for you to use to test out these new features. All examples below use these files.

  • (Audio) : A Recording of the Original Gettysburg Address : gettysburg.wav
  • (Image) : An image of some blueberry plants image.jpg
  • (PDF) : A sample PDF file which contains a fake invoice invoice.pdf

Instructor provides a unified, provider-agnostic interface for working with multimodal inputs like images, PDFs, and audio files. With Instructor's multimodal objects, you can easily load media from URLs, local files, or base64 strings using a consistent API that works across different AI providers (OpenAI, Anthropic, Mistral, etc.).

Instructor handles all the provider-specific formatting requirements behind the scenes, ensuring your code remains clean and future-proof as provider APIs evolve.

Let's see how to use the Image, Audio and PDF classes.


For a more in-depth walkthrough of the Image component, check out the docs here

Instructor makes it easy to analyse and extract semantic information from images using OpenAI's GPT-4o models. Click here to check if the model you'd like to use has vision capabilities.

Let's see an example below with the sample image above where we'll load it in using our from_url method.

Note that we support local files and base64 strings too with the from_path and the from_base64 class methods.

from instructor.multimodal import Image
from pydantic import BaseModel, Field
import instructor
from openai import OpenAI


class ImageDescription(BaseModel):
    objects: list[str] = Field(..., description="The objects in the image")
    scene: str = Field(..., description="The scene of the image")
    colors: list[str] = Field(..., description="The colors in the image")


client = instructor.from_openai(OpenAI())
url = "https://raw.githubusercontent.com/instructor-ai/instructor/main/tests/assets/image.jpg"
# Multiple ways to load an image:
response = client.chat.completions.create(
    model="gpt-4o-mini",
    response_model=ImageDescription,
    messages=[
        {
            "role": "user",
            "content": [
                "What is in this image?",
                # Option 1: Direct URL with autodetection
                Image.from_url(url),
                # Option 2: Local file
                # Image.from_path("path/to/local/image.jpg")
                # Option 3: Base64 string
                # Image.from_base64("base64_encoded_string_here")
                # Option 4: Autodetect
                # Image.autodetect(<url|path|base64>)
            ],
        },
    ],
)

print(response)
# Example output:
# ImageDescription(
#     objects=['blueberries', 'leaves'],
#     scene='A blueberry bush with clusters of ripe blueberries and some unripe ones against a cloudy sky',
#     colors=['green', 'blue', 'purple', 'white']
# )

PDF

Instructor makes it easy to analyse and extract semantic information from PDFs using OpenAI's GPT-4o models.

Let's see an example below with the sample PDF above where we'll load it in using our from_url method.

Note that we support local files and base64 strings too with the from_path and the from_base64 class methods.

from instructor.multimodal import PDF
from pydantic import BaseModel, Field
import instructor
from openai import OpenAI


class Receipt(BaseModel):
    total: int
    items: list[str]


client = instructor.from_openai(OpenAI())
url = "https://raw.githubusercontent.com/instructor-ai/instructor/main/tests/assets/invoice.pdf"
# Multiple ways to load an PDF:
response = client.chat.completions.create(
    model="gpt-4o-mini",
    response_model=Receipt,
    messages=[
        {
            "role": "user",
            "content": [
                "Extract out the total and line items from the invoice",
                # Option 1: Direct URL
                PDF.from_url(url),
                # Option 2: Local file
                # PDF.from_path("path/to/local/invoice.pdf"),
                # Option 3: Base64 string
                # PDF.from_base64("base64_encoded_string_here")
                # Option 4: Autodetect
                # PDF.autodetect(<url|path|base64>)
            ],
        },
    ],
)

print(response)
# > Receipt(total=220, items=['English Tea', 'Tofu'])

Audio

Instructor makes it easy to analyse and extract semantic information from Audio files using OpenAI's GPT-4o models. Let's see an example below with the sample Audio file above where we'll load it in using our from_url method.

Note that we support local files and base64 strings too with the from_path

from instructor.multimodal import Audio
from pydantic import BaseModel
import instructor
from openai import OpenAI


class AudioDescription(BaseModel):
    transcript: str
    summary: str
    speakers: list[str]
    key_points: list[str]


url = "https://raw.githubusercontent.com/instructor-ai/instructor/main/tests/assets/gettysburg.wav"

client = instructor.from_openai(OpenAI())

response = client.chat.completions.create(
    model="gpt-4o-audio-preview",
    response_model=AudioDescription,
    modalities=["text"],
    audio={"voice": "alloy", "format": "wav"},
    messages=[
        {
            "role": "user",
            "content": [
                "Please transcribe and analyze this audio:",
                # Multiple loading options:
                Audio.from_url(url),
                # Option 2: Local file
                # Audio.from_path("path/to/local/audio.mp3")
            ],
        },
    ],
)

print(response)
# > transcript='Four score and seven years ago our fathers..."]

Streaming Support

Instructor has two main ways that you can use to stream responses out

  1. Iterables: These are useful when you'd like to stream a list of objects of the same type (Eg. use structured outputs to extract multiple users)
  2. Partial Streaming: This is useful when you'd like to stream a single object and you'd like to immediately start processing the response as it comes in.

Partials

from instructor import from_openai
import openai
from pydantic import BaseModel

client = from_openai(openai.OpenAI())


class User(BaseModel):
    name: str
    age: int
    bio: str


user = client.chat.completions.create_partial(
    model="gpt-4o-mini",
    messages=[
        {"role": "user", "content": "Create a user profile for Jason, age 25"},
    ],
    response_model=User,
)

for user_partial in user:
    print(user_partial)

# > name='Jason' age=None bio='None'
# > name='Jason' age=25 bio='A tech'
# > name='Jason' age=25 bio='A tech enthusiast'
# > name='Jason' age=25 bio='A tech enthusiast who loves coding, gaming, and exploring new'
# > name='Jason' age=25 bio='A tech enthusiast who loves coding, gaming, and exploring new technologies'

Iterable Example

import os
from openai import OpenAI
import instructor
from pydantic import BaseModel

class User(BaseModel):
    name: str
    age: int

# Extract multiple users from text
users = client.chat.completions.create_iterable(
    model="gpt-4o-mini",
    messages=[
        {"role": "user", "content": """
            Extract users:
            1. Jason is 25 years old
            2. Sarah is 30 years old
            3. Mike is 28 years old
        """},
    ],
    response_model=User,
)

for user in users:
    print(user)
    #> name='Jason' age=25
    #> name='Sarah' age=30
    #> name='Mike' age=28

Instructor Modes

We provide several modes to make it easy to work with the different response models that OpenAI supports

  1. instructor.Mode.TOOLS : This uses the tool calling API to return structured outputs to the client
  2. instructor.Mode.JSON : This forces the model to return JSON by using OpenAI's JSON mode.
  3. instructor.Mode.FUNCTIONS : This uses OpenAI's function calling API to return structured outputs and will be deprecated in the future.
  4. instructor.Mode.PARALLEL_TOOLS : This uses the parallel tool calling API to return structured outputs to the client. This allows the model to generate multiple calls in a single response.
  5. instructor.Mode.MD_JSON : This makes a simple call to the OpenAI chat completion API and parses the raw response as JSON.
  6. instructor.Mode.TOOLS_STRICT : This uses the new Open AI structured outputs API to return structured outputs to the client using constrained grammar sampling. This restricts users to a subset of the JSON schema.
  7. instructor.Mode.JSON_O1 : This is a mode for the O1 model. We created a new mode because O1 doesn't support any system messages, tool calling or streaming so you need to use this mode to use Instructor with O1.

In general, we recommend using Mode.Tools because it's the most flexible and future-proof mode. It has the largest set of features that you can specify your schema in and makes things significantly easier to work with.

Batch API

We also support batching requests using the create_batch method. This is helpful if your request is not time sensitive because you'll get a 50% discount on the token cost.

Read more about how to use it here

Best Practices

  1. Model Selection : We recommend using gpt-4o-mini for simpler use cases because it's cheap and works well with a clearly defined objective for structured outputs. When the task is more ambigious, consider upgrading to 4o or even O1 depending on your needs

  2. Performance Optimization : Streaming a response model is faster and should be done from the get-go. This is especially true if you're using a simple response model.

Common Use Cases

  • Data Extraction
  • Form Parsing
  • API Response Structuring
  • Document Analysis
  • Configuration Generation

Updates and Compatibility

Instructor maintains compatibility with the latest OpenAI API versions and models. Check the changelog for updates.
